型号: PV-LTM5
额定电压: 1500V
额定电流: up to 50A
防护等级: IP68
工作温度: -40℃～85℃
连接器接触电阻：＜0.35mΩ
** Open with special tool**
Item No. | Product Name | Model | Rated V/A | Ø range of cable gland | Conductor cross section | Termimal Type | Ø range of cable gland |
| LTM5-4 | PV Connector | PV-LTM5 | 1500V/30A | 4.5-6.5mm | 2.5-4mm2 | A | Φ7.0 |
| LTM5-6 | PV Connector | PV-LTM5 | 1500V/50A | 5.5-6.5mm | 6mm2 | A | Φ7.0 |
