2000V 铝合金光伏电缆

型号: PV2000DC-AL5

规格: 4mm2~35mm2

额定电压: 2000V dc

证书:  TUV SUD

1. 产品应用

适用于光伏发电系统

2. Cabel Design

Conductor : Aluminum Alloy (AL5)

Insulation: 125℃ Low-Smoke Halogen-Free Flame Retardant Polyolefins

Sheath: 125℃ Low-Smoke Halogen-Free Flame Retardant Polyolefins

Special technology: Electron beam cross-linked

3. Electrical characteristics

Rated voltage: 2000V DC

Temperature range: -40℃ up to +90℃

Max. temperature at conductor: 120℃

4. Warning

4.1. photovoltaic cable shall not be laid overhead without adding metal protective layer.

4.2 photovoltaic cables shall not be immersed in water for a long time.

4.3 PV2K and PV2K-TCA series allow the use of conventional PV connectors, which should be installed by professional electricians

4.4 The PV2K-AL5 series products are only allowed to be directly connected to aluminum or aluminum alloy connectors, such as SSPV-001, SSPV-003, etc.
